MPLAB Starter Kit for PIC24F User’s Guide

4.4

4.5

4.6

4.7

PROGRAMMING THE DEBUGGED APPLICATION

When the program is successfully debugged and running, the next step is to program

the device for stand-alone operation in the finished design. When doing this, the

resources reserved for debug are released for use by the application. To program the

application, use the following steps:

1. Disable starter kits as a debug tool by selecting Debugger>Select Tool>None .

2. Select starter kits as the programmer in the Programmer>Select Programmer

menu.

3. Select Programmer>Program .

Now the starter kit will run independently.

CREATING OTHER APPLICATIONS

This starter kit is just one way to use Microchip PIC24F microcontrollers in an

application. Other tools and resources exist to support these devices.

? PIC24 Demo Boards: Several boards, such as the Explorer 16 Starter Kit, are

available for developing applications.

? MPLAB C30 C Compiler, Full Version: More optimization options than the student

version for full-scale development.

? Application Notes: Libraries and example applications with source code for using

the PIC24F family of microcontrollers.

For more information on demo boards on application notes, see the design center at

the Microchip web site (www.microchip.com). For additional information on the full

version of the MPLAB C30 Compiler, go to http://www.microchip.com/c30 .

DETERMINING DEVICE SUPPORT AND RESERVED RESOURCES

Due to the built-in in-circuit debugging capability of ICD devices and the In-Circuit Serial

Programming? (ICSP?) function offered by the debugger, the starter kit uses some

on-chip resources when debugging. It also uses program memory and file register

locations in the target device during debugging. These locations are not available for

use by user code. In the MPLAB IDE, registers marked with an “R” in register displays

represent reserved registers.

For information on device resources that are needed for in-circuit debugging, please

refer to the MPLAB ICD 2 Help, found in the MPLAB IDE under Help>Topics . The

device reserved resource information found under “Resources Used By MPLAB ICD 2”

is the same for the starter kit.

DEBUG VERSION INFORMATION

Selecting either Debugger>Settings or Programmer Settings from the menu bar opens

the Starter Kit Settings dialog. Currently, there is only one ( Info ) tab on this dialog,

displaying the following information:

? Firmware Version: The version of firmware on the starter kit board.

? Debug Exec Version: The version of the debug executive that is loaded into the

PIC24F device program memory to enable debug operation.

DS51725A-page 24

? 2008 Microchip Technology Inc.
